Product Summary

The TDA2822 is a monolithic integrated circuit in 12+2+2 powerdip, intended for use as dual audio power amplifier in portable radios and TS sets.

Parametrics

TDA2822 absolute maximum ratings: (1)Vs Supply Voltage: 15 V; (2)Io Output Peak Current: 1.5 A; (3)Ptot Total Power Dissipation at Tamb = 50 ℃ at Tcase = 70 ℃: 1.25W; 4W; (4)Tstg, Tj Storage and Junction Temperature: - 40 to 150 ℃.

Features

TDA2822 features: (1)SUPPLY VOLTAGEDOWN TO 3 V; (2)LOWCROSSOVER DISTORSION; (3)LOWQUIESCENT CURRENT; (4)BRIDGE OR STEREO CONFIGURATION.

Diagrams

TDA2822 TYPICAL APPLICATION CIRCUIT
