Product Summary

The SD12CT1G is a transient voltage suppressor with Bi-directional ESD protection with ultra low clamping voltage. The SD12CT1G is designed to protect voltage sensitive components from ESD and transient voltage events. Excellent clamping capability, low leakage, and fast response time, make this part ideal for ESD protection of the SD12CT1G on designs where board space is at a premium. Because of its small size, it is suited for use in cellular phones, portable devices, digital cameras, power supplies and many other portable applications.

Parametrics

SD12CT1G absolute maximum ratings: (1)Peak Power Dissipation @ 20 μs @ TL 3 25℃, Ppk: 350 W; (2)IEC 61000.4.2 (ESD): ±30kV; (3)IEC 61000.4.4 (EFT): 40 A; (4)Storage Temperature Range Tstg: -55 to +150 ℃; (5)Operating Temperature Range TJ: -55 to +125 ℃; (6)Lead Solder Temperature . Maximum (10 Second Duration) TL: 260 ℃.

Features

SD12CT1G features: (1)Peak Power 350W; (2)Low Leakage; (3)Low Clamping Voltage; (4)Small Package for use in Portable Electronics; (5)Meets IEC61000-4-2 Level 4; (6)Meets IEC6100-4-4 Level 4; (7)Meets 16 kV Human Body Model ESD Requirements; (8)Pb-Free Package is Available.

Diagrams

SD12CT1G package dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SD12CT1G
SD12CT1G
ON Semiconductor
TVS Diodes - Transient Voltage Suppressors 12V Bidirectional ESD Protection Diode
Data Sheet
0-1: $0.26
1-25: $0.17
25-100: $0.14
100-500: $0.09
