74HCT154D

4-to-16 line, decoder/demultiplexer, SOP24, -0.5 to +7.0 V, JEDEC standard no. 7A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.47~0.53 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.47~0.53

PartNumber:: 74HCT154D

Brand:: NXP Semiconductors - nxp | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Elina's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-09-16

From Other Seller

Part Number:74HCT154D
US $0.47 - 0.53
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The 74HCT154D is a 4-to-16 line decoder/demultiplexer. The 74HCT154D is a high-speed Si-gate CMOS device and is pin compatible with Low-power Schottky TTL (LSTTL). The device accepts four active HIGH binary address inputs and provide 16 mutually-exclusive active LOWoutputs. The two-input enable gate can be used to strobe the decoder to eliminate the normal decoding glitches on the outputs, or can be used for the expansion of the decoder. The enable gate has two ANDed inputs which must be LOW to enable the outputs. The 74HCT154D can be used as a 1-to-16 demultiplexer by using one of the enable inputs as the multiplexed data input.

Parametrics

74HCT154D absolute maximum ratings: (1)VCC, supply voltage: -0.5 to +7.0 V; (2)IIK, input clamping current, VI < -0.5 V or VI > VCC + 0.5 V: - ±20 mA max; (3)IOK output clamping current VO < -0.5 V or VO > VCC + 0.5 V: ±20 mA max; (4)IO, output current -0.5 V < VO < VCC + 0.5 V: - ±25 mA max; (5)ICC, supply current: 50 mA max; (6)IGND, ground current: -50 mA max; (7)Tstg, storage temperature: -65 to +150 ℃; (8)Ptot, total power dissipation Tamb = -40 ℃ to +125 ℃: 300 mW max.

Features

74HCT154D features: (1)16-line demultiplexing capability; (2)Decodes 4 binary-coded inputs into 16 mutually-exclusive outputs; (3)Complies with JEDEC standard no. 7A; (4)Specified from -40 ℃ to +85 ℃ and -40 ℃ to +125 ℃; (5)ESD protection:HBM EIA/JESD22-A114D exceeds 2000 V; MM EIA/JESD22-A115-A exceeds 200 V.
